Power Management ICs

Developed by ZHONGKE MICROELECTRONICS, part number AT8236 is a single-channel H-bridge brushed DC motor driver engineered to drive small BDC motors widely used within smart home equipment, office automation and compact industrial control hardware. This robust driver features a wide 5.5V–36V operating input range, delivering 3A continuous output current alongside a 6A _Peak transient rating with ultra-low 200mΩ RDS(on) for reduced conduction loss, plus a low-power sleep mode drawing only 20µA quiescent current to minimise standby power drain. As an established UK semiconductor distributor, ABL Semi supplies fully genuine original AT8236 stock with flexible order MOQ options and full pin-to-pin cross-replacement support alongside multi-currency settlement for global procurement needs.

The DIOO DIO5661 is a 37V step-up (boost) constant current LED driver IC designed to drive up to 10 series-connected white LEDs or a 3×13 LED matrix with high brightness consistency, targeting display backlights, automotive interior lighting, and general LED panel applications. Operating at a 1.1MHz switching frequency with up to 86% conversion efficiency, the DIO5661 achieves a maximum output current limit of 1.3A while enabling compact external passive components — a single chip inductor and ceramic capacitors. A unique PWM-to-constant-current dimming mode accepts dimming frequencies from 200Hz to 200kHz for smooth, flicker-free brightness control. An integrated low-side power MOSFET minimises external component count, and built-in protections cover LED open-circuit, thermal shutdown, and cycle-by-cycle current limiting. ABL Semi supplies the DIO5661 as a 100% authentic DIOO product in SOT-23-6 and DFN-6 (2×2mm) with flexible MOQ.

The EG Micro EG44273 is a single-channel, high-speed low-side gate driver IC designed to drive MOSFET and IGBT power switches with fast, rail-to-rail output capability and an ultra-low quiescent current, making it ideal for both high-frequency switching converters and battery-powered applications. Operating from a wide supply range of 4V to 20V, it delivers a symmetric 2A peak source (I_OH) and 2A peak sink (I_OL) output at V_CC = 12V, with a fall time (T_F) of just 20ns for fast, clean turn-off. A standout feature is the exceptionally low quiescent current of below 1µA, minimising no-load power draw in energy-sensitive designs. The output is held low when the input pin is floating, ensuring safe default behaviour. ABL Semi supplies the EG44273 as a 100% authentic EG Micro product in SOT-23-5, with flexible MOQ as a pin-to-pin alternative to the TI UCC27517 and similar low-side drivers.

The Fortior Tech FD6288 is a 3-phase half-bridge gate driver IC integrating three independent high- and low-side driver channels, designed for compact, high-efficiency BLDC motor drive and 3-phase inverter applications. Operating from a supply of 4.8V to 20V with a floating absolute voltage rating of +250V, the FD6288 delivers asymmetric output drive of +1.5A source (I_OH) and -1.8A sink (I_OL) with fast matched rise and fall times of just 12ns each. Built-in 200ns dead time, shoot-through prevention, input filtering, and VCC/VBS undervoltage lockout (UVLO) are all integrated, minimising external component requirements and protecting the power stage under fault conditions. The FD6288 accepts both 3.3V and 5V logic inputs, ensuring broad microcontroller compatibility. ABL Semi supplies the FD6288 as a 100% authentic Fortior Tech product in TSSOP-20 and QFN-24 packages, with flexible MOQ and pin-to-pin compatibility to the IR2130 and equivalent 3-phase gate driver series.

The HEROIC HR4988 is a microstepping bipolar stepper motor driver IC with an integrated translator, enabling precise step resolution control without complex microcontroller sequencing in 3D printers, CNC machines, and industrial automation systems. The HR4988 supports full-, half-, 1/4-, 1/8-, and 1/16-step modes selectable via MSx logic pins, and drives bipolar stepper motors at up to 32V and ±2A, with an on-resistance (R_DS(on)) of 640mΩ. The control interface accepts logic levels of 3V to 5.5V, ensuring direct compatibility with both 3.3V and 5V microcontrollers. An internal synchronous rectification circuit improves PWM efficiency, while thermal shutdown, UVLO, and overcurrent protection are all integrated. ABL Semi supplies the HR4988 as a 100% authentic HEROIC product in a thermally enhanced QFN-28 (5×5mm) package, with flexible MOQ as a pin-to-pin alternative to the Allegro A4988.

The UMW IR21271STR is a high-voltage, high-speed power MOSFET and IGBT gate driver IC built on proprietary HVIC and latch-immune CMOS technology, designed to drive N-channel power switches in high-side or low-side configurations in motor drive, inverter, and power conversion applications. Fully operational to +300V on the floating channel, it accepts logic inputs compatible with 3.3V, 5V, and 15V control signals and operates from a gate drive supply of 8V to 22V. The IR21271STR integrates overcurrent protection that monitors the driven power transistor and terminates gate drive on fault detection, with an open-drain FAULT signal output to notify the host controller — a critical feature for protecting IGBTs and MOSFETs in fault-prone industrial environments. ABL Semi supplies the IR21271STR as a 100% authentic UMW product in SOP-8, with flexible MOQ as a direct pin-to-pin alternative to the Infineon IR21271 series.

MSKSEMI L9110S-MS is a compact low-voltage brushed DC motor driver IC providing a fully integrated H-bridge solution for toys, consumer electronics, and other battery-powered motion control applications, operating across a supply voltage range of 2.5V to 12V. Built around four power NMOS transistors with an internal charge pump for gate drive, the L9110S-MS delivers a continuous output current of 1.2A and a 2A peak current with a combined R_DS(on) of 450mΩ, while an ultra-low standby current of just 100nA (I_q) makes it ideal for always-on battery-powered designs. A PWM INA/INB input interface ensures direct compatibility with standard microcontroller GPIO and PWM outputs, with integrated over-temperature and under-voltage lockout protection. ABL Semi supplies the L9110S-MS in an SOP-8 package with flexible MOQ, 100% authentic factory-original stock, and pin-to-pin replacement support for Western brand equivalents.

The LP103S from LOWPOWER is a high-performance fast charging interface physical layer IC, which monitors USB D+/D- data lines and automatically adjusts power supply output voltage to optimize charging efficiency. This chip features an input voltage range of V_Input 3.1V to 6.3V and ultra-low power consumption below 1mW@5V, supporting mainstream fast charging protocols and output voltages of 5V, 9V, 12V and 20V. As a UK-based distributor, ABL Semi provides 100% original LP103S components with flexible MOQ, pin-to-pin replacement support and complete compliant trade documents for global buyers.

The LP6400 from LOWPOWER is an 18W fast charge synchronous buck regulator built for high-voltage charging solutions. It supports an input voltage range of 8V to 32V and delivers a continuous 3.6A output current at 5V, compatible with QC2.0/3.0, Huawei FCP, Samsung AFC and other mainstream fast charging protocols. With low on-resistance internal MOSFETs and multiple protection functions, this SOP-8 IC greatly cuts down the use of external components. As a UK-based distributor, ABL Semi provides 100% original LP6400 with flexible MOQ and reliable pin-to-pin replacement services.

The MPS MP6540 is a highly integrated 3-phase brushless DC (BLDC) motor driver IC that combines six N-channel power MOSFETs, pre-drivers, gate drive power supplies, and current sense amplifiers into a single compact package — making it ideal for space-constrained, cost-sensitive motor drive applications. It delivers 3A continuous output current and up to 10A peak current for one second, operating across a wide supply voltage range of 5.5V to 35V. An internal charge pump generates the high-side gate drive voltage and a trickle charge circuit maintains reliable operation at 100% duty cycle, while integrated protections including thermal shutdown, UVLO, and over-current protection (OCP) safeguard the system under fault conditions. ABL Semi supplies the MP6540 as a 100% authentic MPS product in the compact QFN-26 (5×5mm) package, with flexible MOQ and pin-to-pin compatibility to TI DRV83xx series motor drivers.

RELMON MS3111S is a compact low-voltage brushed DC motor driver IC delivering an integrated H-bridge driving solution for video cameras, toys, consumer electronics, and other battery-powered motion control applications. Operating from a supply voltage of 1.8V to 6V, the MS3111S provides a continuous output current of 800mA with a 1A peak current capability, and features an on-resistance of just R_DS(on) = 850mΩ for efficient low-voltage operation. A PWM (IN/IN) input interface ensures compatibility with industry-standard microcontrollers and motor control ICs, while integrated over-temperature protection safeguards the device and connected load under fault conditions. ABL Semi supplies the MS3111S in a space-saving SOT-23-6 package with flexible MOQ, 100% authentic factory-original stock, and pin-to-pin replacement options for Western brand equivalents.

RELMON MS8313 is a highly integrated 3-phase brushless DC (BLDC) motor driver IC incorporating three independent half-bridge drivers with low on-resistance power MOSFETs, designed for sensorless or sensored BLDC motor control in consumer, industrial, and home appliance applications. Operating from 8V to 36V, the MS8313 delivers a continuous output current of 1.75A with a 2.5A peak current capability and an R_DS(on) of 240mΩ, while an integrated 3.3V/10mA LDO supplies onboard logic without requiring an external regulator. Low-side current sensing pins, built-in comparators, and a thermally enhanced eTSSOP-28 package with exposed heatsink pad complete a highly self-contained motor drive solution. ABL Semi supplies the MS8313 with flexible MOQ, 100% authentic factory-original stock, and pin-to-pin replacement support for Western brand equivalents.

The WXNSIC NSG2000 is a 250V high-speed, high-side N-channel MOSFET static switch driver IC featuring an integrated dedicated charging circuit that fully enhances external N-channel MOSFETs and sustains conduction indefinitely — enabling true 100% duty cycle high-side switching without bootstrap capacitor recharge limitations. Operating from a gate drive supply of 4.5V to 20V with a quiescent current of just 120µA, the NSG2000 delivers 290mA source (I_HL) and 600mA sink (I_OL) output current with a fast fall time (T_F) of 30ns. It accepts 3.3V, 5V, and 15V logic inputs, includes VIN overvoltage lockout and VCC UVLO protection, and supports an adjustable turn-on duty cycle. ABL Semi supplies the NSG2000 as a 100% authentic WXNSIC product in SOP-8, with flexible MOQ and pin-to-pin compatibility to high-side MOSFET driver ICs from Texas Instruments and Infineon.

The NOVOSENSE NSi6602 is a high-reliability isolated dual-channel gate driver IC designed for driving power switches such as IGBTs, SiC MOSFETs, and GaN FETs in high-voltage, high-frequency applications. It accepts an input supply voltage (V_Input) of 3V to 5V, delivering a 4A peak source (I_OH) and 6A peak sink (I_OL) output with rapid switching transitions of T_r = 7ns and T_f = 6ns. With high common-mode transient immunity (CMTI ±150kV/µs) and isolation ratings up to 5700V_rms, the NSi6602 is well-suited for industrial power conversion, motor drives, and EV charging systems. ABL Semi supplies the NSi6602 with flexible MOQ, supporting both prototype and mass production, with pin-to-pin compatibility to popular Western gate driver alternatives.

The NOVOSENSE NSi6801 is a single-channel isolated gate driver IC engineered as a direct, pin-compatible drop-in upgrade for opto-coupled gate drivers, delivering superior reliability, thermal performance, and switching precision in high-density power conversion systems. It provides 5.2A peak source (I_OH) and 5.4A peak sink (I_OL) output current, with rise and fall times (T_R / T_F) of just 20ns each, enabling fast, precise gate switching of IGBTs, SiC MOSFETs, and GaN FETs. The driver-side supply voltage (V_D) spans 10V to 32V with integrated UVLO, and the device achieves a minimum CMTI of ±150kV/µs for robust noise immunity. ABL Semi supplies the NSi6801 as a 100% authentic NOVOSENSE product with flexible MOQ and pin-to-pin compatibility to popular opto-isolated gate drivers from Broadcom, ON Semiconductor, and Toshiba.

WXNSIC NST03AA is a highly integrated Bluetooth charging dock SoC combining lithium battery charge management, a synchronous boost converter, power path management, and battery protection in a single compact device — purpose-built for wireless audio accessories and USB-charged portable docks. Accepting an input voltage of 4.5V to 5.5V, the NST03AA delivers a 300mA charge current while its synchronous boost converter supports a 0.7A output, all with an ultra-low standby current of just 5µA (I_q). Integrated power path management enables simultaneous charge and discharge with built-in short-circuit and heavy-load protection, eliminating the need for an external diode. ABL Semi supplies the NST03AA in an SOP-8 package with flexible MOQ, 100% authentic factory-original stock, and compliance-friendly UK trade documentation.

The On-Bright OB2263MP is a highly integrated current-mode PWM controller IC optimised for cost-effective, high-performance offline flyback converter designs in the sub-30W power range, targeting chargers, adapters, and consumer power supply applications. Operating from a VDD supply of 10V to 30V with an externally programmable switching frequency trimmed to 60kHz–70kHz and a maximum duty cycle of 75%, the OB2263MP achieves low standby power through extended burst mode operation at no-load and light-load conditions. On-Bright’s proprietary frequency shuffling technique delivers excellent EMI performance, while internal slope compensation, leading-edge blanking on the CS input, and a complete protection suite — including OCP, OLP, UVLO, and 18V gate drive clamp — minimise external component count and system cost. ABL Semi supplies the OB2263MP as a 100% authentic On-Bright product in SOT-23-6, SOP-8, and DIP-8, with flexible MOQ and pin-to-pin compatibility to popular Western flyback PWM controllers.

The Chipown PN8034 is a highly integrated non-isolated AC/DC switching regulator IC that combines a PFM controller with an integrated 650V high-avalanche-capability intelligent power MOSFET and a built-in high-voltage startup circuit — delivering a complete, ultra-compact offline power supply solution with an extremely low external component count. In the DIP-7 package it delivers up to 3.6W at 230VAC, and up to 3.0W at 230VAC in SOP-7, making it ideal for low-power non-isolated SMPS designs in consumer electronics and smart home devices. A built-in frequency reduction modulation technique improves EMI performance, while integrated OCP, OTP, and UVLO protection functions and ultra-low standby power consumption satisfy modern energy efficiency requirements. ABL Semi supplies the PN8034 as a 100% authentic Chipown product in SOP-7 and DIP-7 packages, with flexible MOQ and pin-to-pin compatibility to TNY and NCP series AC/DC regulators.

The Chipown PN8161 is a high-performance quasi-resonant AC/DC converter IC that integrates a current-mode controller and power MOSFET in a compact SOP-8 package, making it ideal for chargers, adapters, and open-frame switching power supplies. With a built-in 690V high-avalanche-capability MOSFET, a maximum switching frequency of 125kHz, and a wide supply voltage range of 9V to 38V, the PN8161 delivers high efficiency across the full load range while keeping external component count to a minimum — no start-up resistors or CS sense resistors required. Its hybrid QR-PWM / QR-PFM / Burst-mode modulation achieves standby power consumption below 50mW at 230VAC, meeting stringent energy efficiency standards. ABL Semi supplies the PN8161 with flexible MOQ for prototyping and production, fully authenticated from Chipown’s original factory.

The Chipown PN8162 is a highly integrated quasi-resonant AC/DC switching regulator that combines a current-mode controller and a built-in 690V high-avalanche-capability power MOSFET in a thermally efficient PDFN-8 (5×6mm) package, purpose-built for chargers, adapters, and open-frame switching power supplies. Operating across a wide supply voltage range of 9V to 38V with a maximum switching frequency of 125kHz, the PN8162 delivers high conversion efficiency with minimal external components — no start-up resistor or CS sense resistor required. Its hybrid QR-PWM / QR-PFM / Burst-mode modulation scheme achieves standby power consumption below 50mW at 230VAC, while integrated Soft Driver and frequency modulation technologies ensure excellent EMI performance. ABL Semi supplies the PN8162 direct from Chipown’s original factory with flexible MOQ for both prototyping and volume production.

The Chipown PN8328 is a highly integrated primary-side constant-current LED driver IC that combines a high-accuracy CC controller and a built-in 650V high-avalanche-capability power MOSFET in a DIP-8 package, designed for isolated dual-winding LED lighting power supplies with an ultra-minimal external component count. Operating across a universal AC input range of 90VAC to 265VAC, the PN8328 achieves ±3% constant current accuracy while eliminating the optocoupler, TL431, transformer auxiliary winding, and high-voltage start-up resistor through Chipown’s patented fast DMOS self-supply and primary-side regulation technologies. Output current is user-adjustable via the R_s resistor on the CS pin, offering flexible luminous flux targeting without circuit redesign. ABL Semi supplies the PN8328 as 100% authentic Chipown product with flexible MOQ and compliance-ready trade documentation for both prototype and production orders.

Prisemi PSC2945 is a highly integrated single-cell Li-ion/Li-polymer battery charger IC combining a switch-mode charger and boost regulator, designed to minimise charging time from USB power sources while enabling USB OTG output from the battery. Supporting an operating input voltage range of 3.2V to 12V, the PSC2945 delivers up to 3A maximum charge current with ultra-low quiescent current of just 10µA (I_q), making it well suited for portable consumer electronics, wearables, and USB-powered handheld devices. Configuration and monitoring are handled via a flexible I²C serial interface, enabling precise control of charging parameters and system settings. ABL Semi supplies the PSC2945 in a compact QFN-24L (4×4mm) package with flexible MOQ, supporting both prototype builds and high-volume production runs with 100% authentic, factory-original components.

CR MICRO PT6010E is a high-voltage multi-cell lithium battery protection IC designed to safeguard 8–10 series Li-ion, LiFePO4, and lithium titanate battery packs against overcharge, over-discharge, overcurrent, and over-temperature conditions across an operating voltage range of 5V to 60V. The PT6010E delivers precise protection with a ±25mV overcharge detection voltage accuracy and ±10mV discharge overcurrent detection accuracy, while independently configurable charge and discharge over-temperature thresholds via external resistors give designers flexible thermal management without firmware overhead. With a quiescent current of just 20µA (I_q) and direct drive capability for external N-type charge and discharge MOSFETs, the device is well suited to high-voltage e-bike, energy storage, and industrial battery pack applications. ABL Semi supplies the PT6010E in an LQFP-32L (7×7mm) package with flexible MOQ and 100% authentic, factory-original stock.

MSKSEMI RZ7899-MS is a robust bidirectional brushed DC motor driver IC designed for single-motor applications including toy drives, automatic valve actuators, and electromagnetic door lock controls across a wide supply voltage range of 3V to 30V. The RZ7899-MS delivers a maximum continuous output current of 6A with an exceptionally low R_DS(ON) of 80mΩ, minimising conduction losses even at high load currents, while an ultra-low standby current of under 1µA preserves battery life in always-on applications. Two logic input pins provide direct forward, reverse, and brake control, with built-in protection covering thermal shutdown, overcurrent limiting, short-circuit protection, and integrated freewheeling diodes for inductive load clamping. ABL Semi supplies the RZ7899-MS in an SOP-8 package with flexible MOQ, 100% authentic factory-original stock, and pin-to-pin replacement options for Western brand equivalents.

The Slkor SL27517 is a single-channel, low-side MOSFET and IGBT gate driver IC featuring a dual-input design configurable for either non-inverting or inverting operation, making it exceptionally flexible for PWM control, enable/disable, and logic inversion applications in switching power converters. Operating from a wide supply range of 4.5V to 20V (rated up to 24V), the SL27517 delivers a fast and symmetric 4A peak source (I_OH) and 4A peak sink (I_OL) output current with industry-leading rise and fall times of just 6ns each — among the fastest in the SOT-23-5 gate driver class. Negative input capability down to -5V, TTL/CMOS logic compatibility, output-low failsafe on floating input, and a propagation delay typically below 20ns complete a compelling feature set. ABL Semi supplies the SL27517 as a 100% authentic Slkor product in SOT-23-5, with flexible MOQ and direct pin-to-pin compatibility to the TI UCC27517 and equivalent low-side gate drivers.

The Sillumin SLM27211 is a high-frequency N-channel MOSFET half-bridge gate driver with independently controlled high-side and low-side outputs and an integrated 120V bootstrap diode, designed for half-bridge, full-bridge, two-switch forward, and active clamp forward converter topologies. Operating from a supply (V_DD) of 8V to 17V, the SLM27211 delivers 3A sink (I_OL) and 4.5A source peak gate drive current, with a fast rise time (T_r) of 7ns and fall time (T_f) of 5ns. High-side and low-side channels are matched to within 2ns of each other, and the on-chip bootstrap diode eliminates the need for an external discrete diode. Both channels include independent UVLO protection. ABL Semi supplies the SLM27211 as a 100% authentic Sillumin product across four package options, with flexible MOQ and pin-to-pin compatibility to the UCC27211 and IR2110 series.

The Sillumin SLM343 is an opto-compatible, single-channel isolated gate driver for IGBTs and MOSFETs, engineered as a direct pin-to-pin drop-in upgrade over traditional optocoupler-based gate drivers in both high-side and low-side power switch configurations. It delivers 4A peak source (I_OH) and 6A peak sink (I_OL) output current, with a 5000V_RMS reinforced isolation rating and an input supply range of 14V to 40V. The SLM343 uses an emulated diode input stage — eliminating LED aging degradation — and achieves high common-mode transient immunity (CMTI) with low propagation delay and minimal pulse width distortion. Housed in a stretched SO-6 (6.8mm) package with over 8.5mm creepage and clearance and CTI >600V mould compound, it meets reinforced isolation requirements. ABL Semi supplies the SLM343 as a 100% authentic Sillumin product with flexible MOQ and pin-to-pin compatibility to Broadcom and Toshiba opto-isolated gate drivers.

The Silergy SY50213W is a primary-side regulated (PSR) flyback AC/DC switching regulator designed for compact, cost-efficient constant current / constant voltage (CC/CV) power supply applications. By integrating an 800V breakdown voltage bipolar NPN transistor directly into a compact SO-8 package, the SY50213W eliminates the need for an opto-isolator and secondary-side feedback circuitry, reducing overall BOM cost and board space. It delivers up to 2.1A output current with a power dissipation of 1.1W, and accepts an input voltage range of 6V to 14V on the control side, with quasi-resonant PWM/PFM operation achieving high average efficiency and low EMI. ABL Semi supplies the SY50213W as a 100% authentic Silergy product with flexible MOQ, suitable as a pin-to-pin alternative to comparable flyback controllers from Power Integrations and onsemi.

The Silergy SY7200A is a DC/DC step-up (boost) LED driver IC that delivers accurate, regulated constant current for driving series-connected LED strings — making it ideal for compact backlight and general LED lighting designs in portable and consumer electronics. Operating from a wide input voltage range of 2.8V to 30V, the SY7200A switches at a fixed frequency of 1MHz, enabling the use of small-value ceramic capacitors and inductors that minimise PCB footprint and BOM cost. It supports EN/PWM dimming input frequencies from 20kHz to 1MHz for flicker-free brightness control, and can drive up to eight white LEDs in series with output voltage up to 30V, with LED current set accurately by a single external resistor. The device operates across -40°C to 85°C and is RoHS compliant and halogen-free. ABL Semi supplies the SY7200A as a 100% authentic Silergy product in SOT-23-6 with flexible MOQ and pin-to-pin compatibility to comparable boost LED drivers.

The UMW UCC27517DBVR is a single-channel, low-side in-phase gate driver IC for power MOSFETs and IGBTs, built on proprietary latch-immune CMOS technology for high robustness in demanding switching power applications. Operating from a wide supply range of 5V to 25V, it delivers a symmetrical 4A source (I_OH) and 4A sink (I_OL) peak output current with fast matched rise and fall times of just 10ns each, enabling precise, low-loss gate switching at high frequencies. The logic input is compatible with CMOS, TTL, and 3.3V signal levels, and integrated UVLO with hysteresis prevents under-driven gate conditions during supply ramp events. The device operates across a wide temperature range of -40°C to 125°C. ABL Semi supplies the UCC27517DBVR as a 100% authentic UMW product in the compact SOT-23-5 package, with flexible MOQ as a direct pin-to-pin alternative to the TI UCC27517.

The UMW 78L05 is a fixed 5V monolithic linear voltage regulator from UMW’s 78L series, designed to deliver a stable, regulated 5V output at up to 100mA from input voltages up to 30V — making it ideal for powering low-current logic circuits, reference voltage rails, sensors, and signal conditioning stages in both consumer and industrial electronics. With a quiescent current (I_q) of 2mA and a fixed V_Output of 5V, the UMW 78L05 requires only small input and output bypass capacitors for stable operation, minimising BOM complexity in space-constrained designs. The device is housed in a compact SOT-89-3 package with a pinout compatible with the industry-standard 78L05 family used across multiple manufacturers. ABL Semi supplies the UMW 78L05 as a 100% authentic factory product with flexible MOQ and direct pin-to-pin compatibility to the TI UA78L05, onsemi MC78L05, and ST L78L05 series.

The UMW AMS1117 is a positive low-dropout (LDO) linear voltage regulator delivering up to 1A continuous output current with a typical dropout voltage of just 1.2V at 1A, making it one of the most widely deployed LDO regulators in consumer electronics, embedded systems, and industrial power supply designs. Available in both fixed output voltage versions (1.2V, 1.5V, 1.8V, 2.5V, 3.3V, and 5.0V) and an adjustable (ADJ) version, the UMW AMS1117 provides output accuracy of 2% on fixed versions and 1.5% on the adjustable version — ensuring precise, stable regulation across load and temperature variations. UMW manufactures the AMS1117 in SOT-223, TO-252, and SOT-89 packages for broad PCB layout compatibility. ABL Semi supplies the UMW AMS1117 as a 100% authentic product with flexible MOQ, serving as a pin-to-pin replacement for AMS1117 devices from Advanced Analogic, Diodes Inc., and other established brands.

UMW L9110S is a dual-channel push-pull motor driver IC — a two-channel power amplifier ASIC designed to drive brushed DC motors, stepper motor windings, solenoid valves, and switching power circuits in low-voltage battery-powered applications. Operating from a supply voltage of 2.2V to 6.5V, the L9110S provides two independent output channels each capable of 200mA continuous output current at V_CC = 5V, with a low saturation voltage drop for efficient low-voltage operation. Both input control terminals are fully TTL/CMOS compatible, enabling direct connection to 3.3V or 5V microcontroller I/O pins without level-shifting components, and the device requires minimal external circuitry to implement complete bidirectional motor or valve drive. ABL Semi supplies the UMW L9110S in an SOP-8 package with flexible MOQ and 100% authentic, factory-original stock.

The UMW LM2596 is a 150kHz fixed-frequency PWM step-down (buck) switching regulator IC providing all the active functions needed to build a complete, high-efficiency buck converter capable of delivering a guaranteed 3A continuous output current with excellent line and load regulation of ±4% maximum. Available in fixed output voltage versions of 3.3V, 5V, and 12V, plus an adjustable (ADJ) version covering 1.2V to 37V (57V for the HV variant), the LM2596 requires only 4 external components and integrates internal frequency compensation and a fixed-frequency oscillator — eliminating external compensation design. A low-power standby mode draws just 80µA, and TTL-compatible shutdown, thermal protection, and current limiting are all built in. The UMW LM2596 is available in TO-220, TO-220B, and TO-263 packages. ABL Semi supplies it as a 100% authentic UMW product with flexible MOQ and pin-to-pin compatibility to the TI LM2596 series.

The UMW PT4115 is a 30V, 1.2A step-down constant current LED driver IC operating in continuous inductor current conduction mode, designed to drive one or more series-connected LEDs at up to tens of watts with outstanding efficiency of up to 97%. Accepting a wide DC input range of 6V to 30V and switching at 1MHz, the PT4115 enables compact external passive components while maintaining output current accuracy of ±5%. A single multiplexed DIM pin supports LED on/off switching, analogue dimming, and wide-range PWM dimming — with the device entering an ultra-low standby current state when DIM voltage falls below 0.3V. An integrated power switch and high-side current sensing minimise external component count. ABL Semi supplies the UMW PT4115 as a 100% authentic product in SOT-89-5, with flexible MOQ and pin-to-pin compatibility to the original PT4115 and AL8805 series LED drivers.

UMW TP4056 is a high-performance single-cell Li-ion battery linear charger IC utilising a constant current/constant voltage (CC/CV) charging architecture, designed for compact portable products powered by USB or adapter supplies. Supporting an input voltage range of 4V to 6.5V, the TP4056 fixes the charge termination voltage at 4.2V with an externally programmable charge current, and enters a low-power sleep state drawing less than 1µA battery leakage when the input is disconnected. A standby quiescent current of just 35µA (I_q) and support for 0V battery charging make the UMW TP4056 particularly well suited to deeply discharged cell recovery in power banks, wearables, and IoT devices. ABL Semi supplies the UMW TP4056 in an ESOP-8 package with flexible MOQ and 100% authentic, factory-original stock.

The UMW XL1509 is a 150kHz fixed-frequency PWM buck (step-down) DC/DC converter IC capable of delivering 2A continuous output current with high efficiency, low output ripple, and excellent line and load regulation across a wide input voltage range of up to 45V. Available in fixed output versions of 3.3V, 5V, and 12V as well as an adjustable (ADJ) version, the XL1509 integrates internal frequency compensation, a fixed-frequency oscillator, and an enable function — minimising external component count and simplifying PCB design significantly. A built-in two-stage overcurrent protection reduces switching frequency from 150kHz to 50kHz under sustained overload conditions, protecting the converter and downstream load. The PWM duty ratio is adjustable from 0% to 100%. ABL Semi supplies the UMW XL1509 in SOP-8 and ESOP-8 packages with flexible MOQ and pin-to-pin compatibility to the XL4005 and LM2596 buck regulator series.

The NCE XJNG2103 is a 200V high-voltage, high-speed half-bridge gate driver IC with dependent high-side and low-side referenced output channels, built on proprietary HVIC and latch-immune CMOS technology for ruggedised monolithic construction in demanding motor drive and power conversion applications. The floating channel supports bootstrap operation fully up to +200V, driving an N-channel MOSFET in the high-side configuration, while both channels deliver a symmetric 1A source (I_OH) and 1A sink (I_OL) peak output current with rise and fall times of 50ns and 40ns respectively. Operating from a gate drive supply of 9V to 20V with a quiescent current of just 160µA, the XJNG2103 accepts 3.3V, CMOS, and LSTTL logic inputs and is tolerant to negative transient voltages. ABL Semi supplies the XJNG2103 as a 100% authentic NCE product in SOIC-8, with flexible MOQ and pin-to-pin compatibility to the Infineon IR2103 series.
